GV8GA Series AC Charging Pile (Type 1 / Type 2)

7.4–22kW · Type 1 & Type 2 · Indoor / outdoor · CE / RoHS / FCC

Two versions: Type 1 (SAE J1772) and Type 2 (IEC 61851).
Power ratings from 7.4kW to 22kW.
Type 1: 120VAC ±15% / 240VAC ±15%, up to 11kW / 48A.

Chat on WhatsApp Inquire Now Email Us

CE RoHS FCC

Overview

The GV8GA series is an AC charging pile supplied in two versions: Type 1 (SAE J1772) for 120VAC / 240VAC networks, and Type 2 (IEC 61851) for 230VAC single-phase and 400VAC three-phase networks. Power ratings run from 7.4kW to 22kW. The compact 16.5 × 9.5 × 25 cm enclosure can be installed indoors or outdoors, and the unit carries CE, RoHS and FCC certification.

Key Features

Two versions: Type 1 (SAE J1772) and Type 2 (IEC 61851).
Power ratings from 7.4kW to 22kW.
Type 1: 120VAC ±15% / 240VAC ±15%, up to 11kW / 48A.
Type 2: 230VAC ±15% single phase / 400VAC ±15% three phase, up to 22kW / 32A.
50–60Hz operating frequency.
Compact 16.5 × 9.5 × 25 cm enclosure.
Indoor or outdoor installation.
CE, RoHS and FCC certified.
OEM & ODM customization — product appearance, charging gun head, plug, cable colour and packaging.
Card-swipe start-up, plus Bluetooth / Wi-Fi and RFID control options.
7kW fast charging at 32A max, quicker than other standard wallboxes.

Applications

Home charging
Apartment and residential parking
Office and workplace charging
Hotel and retail destination charging

Specifications

GV8GA series — full specification by connector standard
Standard	Type 1	Type 2	GBT	Tesla
Product Model	GV8GA series
Size	18.59.529cm
Voltage	120Vac±15% / 240Vac±15%	230Vac±15% (Single phase) / 400Vac±15% (Three phase)	220Vac±15% (Single phase) / 380Vac±15% (Three phase)	120Vac±15% / 240Vac±15%
Power / Amperage	7.6kW / 32A, 9.6kW / 40A, 11kW / 48A	7.4kW / 32A, 11kW / 16A, 22kW / 32A	7.4kW / 32A, 11kW / 16A, 22kW / 32A	7.6kW / 32A, 9.6kW / 40A, 11kW / 48A
Installation Method	Indoor / Outdoor
Frequency	50-60Hz
Certificate	CE, RoHS, FCC
Charging Interface	SAE J1772	IEC 61851	GB/T18487	SAE J1772
Multiple Protection	Ground protection, leakage protection, over-voltage protection, over-current protection, leakage protection, over-
Enclosure Material	94V0 Sable PC
Cable Material	TPU	TPU	EV	TPU
Operating Temperature	80°C (protection) / 60°C (recovery)
Indoor / Outdoor	IP65
Relative Humidity	Up to 95% non-condensing
Supported Features	Bluetooth / Wi-Fi, RFID
Optional content
HCI	4.3 inch square screen, no screen
RCD	TypeA (Standard); or	TypeA (Standard); or	TypeA (Standard); or	TypeA (Standard); or
Color	Black(Standard); White, Red, Green, Blue, Pink
Installation Method	Wall mounted / with column
Working Mode	Domestic (Standard) / Commercial
OCPP	ocpp1.6J (Standard) or ocpp2.0
Supported Features (optional)	4G, Ethernet
Cable Length (accept customization)	18ft (5m) Standard	18ft (5m) Standard	18ft (5m) Standard	18ft (5m) Standard
Current Regulation	8A-10A-13A-16A-20A-24A-32A (optional 40A-48A)	8A-10A-13A-16A-20A-24A-32A	8A-10A-13A-16A-20A-24A-32A	8A-10A-13A-16A-20A-24A-32A (optional 40A-48A)
