Portable Charging

Portable EV Charger (16A / 3.5kW)

AC110V · 3.5kW · 8–16A adjustable · Ruggedized

Working voltage AC110V, rated power 3.5kW.
Adjustable current: 8A / 10A / 13A / 16A.
50Hz operating frequency.

Chat on WhatsApp Inquire Now Email Us

Overview

A portable EV charger designed for everyday and emergency charging. Working voltage is AC110V with a rated power of 3.5kW, and the current is adjustable across 8A, 10A, 13A and 16A. The unit is built to withstand real-world handling: a mechanical life of more than 10,000 no-load plug-in/plug-out cycles, resistance to a 1 m drop and a 2-tonne vehicle run-over, and an insulation resistance above 500MΩ at DC 500V.

Key Features

Working voltage AC110V, rated power 3.5kW.
Adjustable current: 8A / 10A / 13A / 16A.
50Hz operating frequency.
Mechanical life of more than 10,000 no-load plug-in / plug-out cycles.
Withstands a 1 m drop and a 2-tonne vehicle run-over.
Insulation resistance above 500MΩ (DC 500V).
Portable format for travel and emergency charging.
IP65 charging head with safety insulation design and automatic dust filtering.
TPU cable — abrasion resistant, corrosion resistant and high-temperature resistant.
Fingerprint unlocking, LED charging indicator and an LCD status screen.
Optional UK, USA, Australia and European power plugs.

Applications

Home and residential charging
Travel and roadside emergency charging
Fleet and rental vehicle support
Dealer demonstration

Specifications — Portable EV Charger (16A / 3.5kW)
Product Name	Portable EV Charger
Working Voltage	AC110V
Current	16A (8-10-13-16A)
Rated Power	3.5kW
Frequency	50Hz
Mechanical Life	No-load plug in/pull out > 10,000 times
Impact of External Force	1 m drop and 2T vehicle run over pressure
Insulation Resistance	> 500MΩ (DC 500V)
Place of Product	Guangdong Province, China
